Pinax.jl

A board of figures that is also a catalogue.

Pinax turns the figures your analysis scripts produce into a structured, self-contained HTML gallery — sections as cards, a multi-column figure grid, markdown + math descriptions, cross-references, citations, and an interactive comment layer — and can export the same manuscript to PDF via a LaTeX theme.

It generalizes the hand-written build_report page that an analysis pipeline grows over time: you describe the manuscript once with a small DSL, point each figure at the value (or data key) it plots, and render writes the gallery.

The shape of it

using Pinax

@page :results "Results" begin
    @section :energy "Energy" begin
        @desc md"Energy density $E/N$ versus inverse temperature $\beta$."
        @figure plot_energy()          # any Plots/Makie figure — deferred until render
        @caption "χ-convergence"
    end
end

render(out = "site")                    # -> site/index.html  (self-contained)
# render(theme = :latex, out = "pdf")   # -> pdf/document.tex -> PDF

@figure captures its expression lazily, so figures are only computed (and cached) when you render. Sections become cards; figures lay out in a responsive grid; $…$ math is rendered by KaTeX; serve("site") previews it over HTTP.

Where to go next

• Examples — a map of contents across every compiled gallery (a LaTeX-style table of contents that spans them all), plus a source walkthrough for each. Every gallery is built live as a Documenter @example and rendered by Pinax.
• API Reference — every exported macro and function.
